ITEMS/MODEL NO.
 SKTH-4 SKTH-5 SKTH-6 SKTH-10 SKTH-15
DIMENSION OF WORKPIECE Ø400×600L Ø500×900 L Ø600×1200L Ø1000×1500L Ø1500×2500L
WEIGHT OF WORKPIECE 150kg 200kg 250kg 350kg 400kg
IMPELLER UNIT Ø360×15HP×2SET Ø360×15HP×4SET Ø360×15HP×6SET Ø360×15HP×8SET Ø360×15HP×12SET
WEIGHT OF
ABRASIVE		 360kg/min 720kg/min 1080kg/min 1440kg/min 2160kg/min
KIND OF
TROLLEY CHAIN		 TR-348 TR-348 TR-458 TR-458 TR-678
PASS SPEED 0.5-2m/min 0.5-3m/min 0.5-3m/min 0.5-3m/min 0.5-3m/min
